089: Кожух цепи ГРМ — HITACHI ZX40U
Схема и каталожные номера деталей узла «089: Кожух цепи ГРМ» для экскаватора HITACHI ZX40U.
Схема узла
Каталожные номера
| Позиция | Наименование | Каталожный номер | Кол. |
|---|---|---|---|
| 001 | FLYWEIGHT | 8973104521 | 1 |
| 005 | SLEEVE FLYWEIGHT | 8971474893 | 1 |
| 006(A) | SHAFT LEVER | 9081608500 | 1 |
| 006(A) | SHAFT LEVER | 9081508500 | 1 |
| 006(B) | SHAFT LEVER | 9081605450 | 1 |
| 006(B) | SHAFT LEVER | 9081505450 | 1 |
| 006(C) | SHAFT LEVER | 8970164460 | 1 |
| 007 | COVER GOV SHAFT | 8971617641 | 1 |
| 007 | COVER GOV SHAFT | 8981138040 | 1 |
| 016 | PIN LEVER TO LINK PLATE | 1097470020 | 1 |
| 018 | PLATE LINK,LEVER TO PUMP | 8971485500 | 1 |
| 021 | GASKET SCREW | 5095031321 | 2 |
| 022(A) | NUT SCREW | 9091114060 | 2 |
| 022(A) | NUT SCREW | 0911115060 | 2 |
| 022(B) | NUT SCREW | 9091104060 | 1 |
| 022(B) | NUT SCREW | 9091114060 | 1 |
| 022(B) | NUT SCREW | 0911105060 | 1 |
| 022(B) | NUT SCREW | 0911115060 | 1 |
| 024 | NUT CAP,SCREW | 5094000480 | 1 |
| 025 | CAP IDLE SET | 5156690021 | 1 |
| 027 | LEVER CONT | 8970493281 | 1 |
| 028(A) | LEVER MAIN SPR | 8970346424 | 1 |
| 029 | GASKET SHAFT,CONT | 1096230550 | 2 |
| 030 | SPRING RETURN,CONT | 8973070610 | 1 |
| 031 | WASHER THRUST,LEVER | 5095031350 | 2 |
| 032 | NUT LEVER TO SHAFT | 9091105080 | 1 |
| 032 | NUT LEVER TO SHAFT | 0911105080 | 1 |
| 034 | EYE START SPR | 5157292392 | 1 |
| 035 | SPRING MAIN,LEVER | 8971712420 | 1 |
| 036 | SPRING START | 8970843251 | 1 |
| 037(A) | SPRING IDLE | 8972447701 | 1 |
| 039 | ANGLEICH KIT | 8973213502 | 1 |
| 040 | NUT HOLDER | 8941304380 | 1 |
| 043 | LEVER FUEL CUT | 8973034540 | 1 |
| 044(A) | GASKET COVER | 8970646881 | 1 |
| 045 | BUSHING GEAR CASE TO CONT LEVER | 8972628830 | 1 |
| 046(A) | BOLT COVER | 0280806200 | 3 |
| 046(A) | BOLT COVER | 0280506200 | 3 |
| 046(D) | BOLT COVER | 8971322912 | 2 |
| 046(E) | BOLT COVER | 8971322922 | 1 |
| 049(A) | PLUG COVER,GOV | 1096050190 | 1 |
| 050 | LEVER GUIDE | 8973035772 | 1 |
| 051 | COVER ADJ | 8971259740 | 1 |
| 051 | COVER ADJ | 8973580001 | 1 |
| 052 | PIECE GUIDE | 8973035830 | 1 |
| 053 | PIN GUIDE LEVER | 1097470020 | 1 |
| 054 | LEVER TENSION,GOV | 8970346376 | 1 |
| 055 | SHIFTER GOV | 8970346383 | 1 |
| 056 | SHAFT SHIFTER | 8973036670 | 1 |
| 057 | RING SNAP,SHAFT | 9091854040 | 1 |
| 057 | RING SNAP,SHAFT | 0918055040 | 1 |
| 058 | LEVER FLOATING | 8973035802 | 1 |
| 059 | PLUG SHAFT,FLOATING LEVER | 1096050500 | 1 |
| 059 | PLUG SHAFT,FLOATING LEVER | 8973695521 | 1 |
| 060 | LINK CONT,INJ PUMP | 8971488650 | 1 |
| 061 | SCREW SET,FULL LOAD | 8970395842 | 1 |
| 062 | SCREW SET,IDLE SPR | 8970164410 | 1 |
| 063(A) | WASHER IDLE SPR | 9091605040 | 1 |
| 063(A) | WASHER IDLE SPR | 0916105040 | 1 |
| 063(B) | WASHER IDLE SPR | 9091607040 | 1 |
| 063(B) | WASHER IDLE SPR | 0916107040 | 1 |
| 064 | RING SNAP,SET SCREW | 9091854030 | 1 |
| 064 | RING SNAP,SET SCREW | 0918055030 | 1 |
| 065 | SCREW CONT SET SPEED | 5091200151 | 1 |
| 065 | SCREW CONT SET SPEED | 8943176381 | 1 |
| 066 | WASHER LK | 9091505080 | 2 |
| 066 | WASHER LK | 0915105080 | 2 |
| 066 | WASHER LK | 0915108080 | 2 |
| 067 | PIN SPR,CONT | 9081604360 | 1 |
| 067 | PIN SPR,CONT | 9081504360 | 1 |
| 069 | SPRING SET | 8970837141 | 1 |
| 070(A) | COVER ANGLEICH | 8973074671 | 1 |
| 071 | CUP SEALING | 5111290060 | 1 |
| 072 | GASKET COVER,ANGLEICH | 8972268421 | 1 |
| 073 | SPRING FUEL CUT | 8970395461 | 1 |
| 074 | NUT SHAFT | 9091105080 | 1 |
| 074 | NUT SHAFT | 0911105080 | 1 |
| 075 | BUSHING LEVER,MAIN SPR | 8972628170 | 1 |
| 076 | CUP SEALING,BUSHING | 8944546150 | 1 |
| 077 | LEVER KIT GOV | 8970935494 | 1 |
| 094(A) | GASKET BUSH | 9095651140 | 1 |
| 094(B) | GASKET BUSH | 9095651160 | 1 |
